0.5m 1m 1.5m 2m Madrix 3D video pixel tube is available, it can make led matrix.
1, DMX512 led pixel video light tube is 360 degree viewing, it can display 3D animations.
2, LED madrix 3D pixel tube light is DMX or SPI dimmable, each pixel of led video light is programmable.
3, Programmable led Madrix 3D tube light is rgb full color, compatible with Madrix, sync with music.
4, Clear housing, milky housing, silver housing, and gold housing dmx512 3D led tube is available.
5, OEM/ODM dmx 3D led tube light is offered.
|
Model NO.
|
LED-3DT30DMX3208
|
LED-3DT30DMX6416
|
LED-3DT30DMX9624
|
LED-3DT30DMX12832
|
|
Diameter
|
30mm
|
30mm
|
30mm
|
30mm
|
|
Length
|
500mm
|
1000mm
|
1500mm
|
2000mm
|
|
Color
|
■■■ RGB full color
|
■■■ RGB full color
|
■■■ RGB full color
|
■■■ RGB full color
|
|
LED QTY
|
32LEDs
|
64LEDs
|
96LEDs
|
128LEDs
|
|
Pixel QTY
|
8 Pixels
|
16 Pixels
|
24 Pixels
|
32 Pixels
|
|
Tube Qty/Universe
|
20 Tubes
|
10 Tubes
|
7 Tubes
|
5 Tubes
|
|
Voltage
|
DC15V
|
DC15V
|
DC15V
|
DC15V
|
|
Power
|
MAX=8W
|
MAX=16W
|
MAX=24W
|
MAX=32W
|
|
Protocol
|
DMX512
|
DMX512
|
DMX512
|
DMX512
|
|
Address Setting
|
Manually
|
Manually
|
Manually
|
Manually
|
|
Protection
|
IP65
|
IP65
|
IP65
|
IP65
|
|
Note
|
1, Diameter: 15mm, 30mm, 50mm
2, Length: 0.5m, 1m, 1.5m, 2m
3, Voltage: 12V, 15V, 24V
|
|
Model NO.
|
LED-3DT30SPI3208
|
LED-3DT30SPI6416
|
LED-3DT30SPI9624
|
LED-3DT30SPI12832
|
|
Diameter
|
30mm
|
30mm
|
30mm
|
30mm
|
|
Length
|
500mm
|
1000mm
|
1500mm
|
2000mm
|
|
Color
|
■■■ RGB full color
|
■■■ RGB full color
|
■■■ RGB full color
|
■■■ RGB full color
|
|
LED QTY
|
32LEDs
|
64LEDs
|
96LEDs
|
128LEDs
|
|
Pixel QTY
|
8 Pixels
|
16 Pixels
|
24 Pixels
|
32 Pixels
|
|
Tube Qty/Universe
|
20 Tubes
|
10 Tubes
|
7 Tubes
|
5 Tubes
|
|
Voltage
|
DC15V
|
DC15V
|
DC15V
|
DC15V
|
|
Power
|
MAX=8W
|
MAX=16W
|
MAX=24W
|
MAX=32W
|
|
Protocol
|
SPI
|
SPI
|
SPI
|
SPI
|
|
Protection
|
IP65
|
|
Note
|
1, Diameter: 15mm, 30mm, 50mm
2, Length: 0.5m, 1m, 1.5m, 2m
3, Voltage: 12V, 15V, 24V
|
